Detailed Selling Lead DescriptionBrand: CHINA WINS
Model: ZQTQ-F1200-ZY
Min. Order: 1
Name: Tire Ring-cutting Machine
Type: ZQTQ-F1200-ZY
Main uses: The machine is to cut off the tire lip steel ring, prolong the life span of the next machine's cutter,and facilitate the later work.
Technical parameters:：1、Capacity 600---800KG/H
2、Motor power 1.5KW
3、Outside size: 1340×990×820
4、Applicable tire interior diameter 750---1200mm
5、Pressed gas pressure 6---8Mpa
6、Expanding jaw rev
Principle and character: The pneumatic cylinder raises and fixes the tire, by coupling device, the electric motor turns the tire, the feeding cutter on the carriage stretches out and cuts off the tire lip in either side.
1.The feeding cutter’s body is made of excellent alloy steel, the blade is made by build-up welding with high rigidity wearable alloy welding rod, a long life-span, able to be repaired by repeated build-up welding and blade-grinding.
2.The tire is easy to be installed, with a short reciprocating stroke, and the machine is productive.
3. Manual and automatic working means, easy to operate.
4. Simple structure, light in weight, occupying a small area.
|
